Coliter ® Magnetically Locked Ball Valve with Thermometer and Strainer – PN16
QF6010 Magnetically Locked Ball Valve with Thermometer and Strainer
The Coliter® QF6010 Magnetically Locked Ball Valve with Thermometer and Strainer is an advanced lead-free brass valve designed for secure, monitored, and filtered water service in residential, commercial, and utility applications. It integrates three critical functions into a single compact unit: a magnetically locked full-port ball valve (operable only with a proprietary magnetic key), a built-in Y-type strainer to protect downstream equipment from debris, and a dedicated thermometer port for real-time temperature monitoring. Rated at PN16 (1.6 MPa) and suitable for water within a temperature range of -20°C to 100°C, it features ISO 228 (BSP) parallel threads and is constructed from high-quality forged brass with PTFE seals for reliable bubble-tight shut-off. Compliant with WRAS, ACS, EN, and GB standards, the QF6010 is ideal for heating systems, solar thermal installations, district energy substations, and smart metering points where tamper resistance, filtration, and thermal diagnostics are required.
Installation diagram
Product Description
| DN | G | D | L | H |
| 20 | G3/4" | 17 | 55 | 43 |
| 25 | G1" | 22 | 65 | 48.5 |
| 32 | G1¼ | 30 | 71 | 53 |
Technical Specifications
Nominal Pressure: 1.6 MPa
Working Medium: Water, Oil, Steam
Working Temperature: -20℃ ≤ t ≤ 100℃
Pipe Threads: ISO 228
Product Inquiry
We will contact you within one working day. Please pay attention to your email.
Faq - Frequent questions
Introduction to Brass Valve With Lock
Coliter® provides a specialized range of brass valves with integrated locking mechanisms to prevent unauthorized operation in residential, municipal, and utility applications. The series includes magnetically locked ball valves (e.g., QF6002, QF6213, QF6313) requiring a proprietary magnetic key, mechanically locked models (e.g., QF6327) with slide or pin locks, and multi-lock variants (QF6223) for enhanced security. Many feature built-in Y-strainers or thermometers for added functionality. All are made from lead-free brass, comply with WRAS, ACS, EN, and GB standards, and operate up to PN16 (1.6 MPa) and 100–120°C. Ideal for water meter isolation, rental properties, and public infrastructure—combining tamper-proof control with certified safety for potable water systems.
